Submersible Sewage & Wastewater Pump

Specifications:

  • Size: 50~600mm
  • Capacity: 10~6000 m³/h
  • Head: 5~62m
  • Speed: 750~3550r/min
  • Temperature Range: ≤80°C
  • Sealing arrangement: Mechanical seal
  • Rated voltage: 110V~1000V
  • Rated frequency: 50Hz and 60Hz
  • Materials: Cast iron/SS304/SS316L/Duplex SS/ High chrome/Hyper chrome etc

The advantages are also very obvious such as the relatively cheap price of the equipment in its class which saves on routine maintenance and transportation costs. In addition, it has a longer service life as it is very well constructed and designed for durability and reliability. All in all, this equipment is easy to operate and flexible to use, which greatly improves the working efficiency and operation effect.

Portable submersible sewage pump is great for solving some difficult tasks and make a positive contribution to clean environment and marine protection. Its reliability, flexibility as well as portability are irreplaceable and can be considered as an essential tool. As more and more people appreciate its multi-faceted advantages. The use of this equipment will become more and more widespread and exert more social value.

Products Detail:

Submersible Sewage Pumps are adopted the advanced technique especially suitable for transmission the liquids that contain solid and fiber matters and dirty stick slippery liquid. With the cutting device installed inside in advance, all Submersible pump can tear off the long fiber matters such bags, belt, grass and cloth. Then discharge it with water. Therefore it can run more smoothly and reliable in waste water, without being blocked.

Products Design Features:

  • With advanced technique, larger discharge capacity, non clogged. It can effectively discharge the solid grain with diameter of 30~80mm.
  • The cutting device will tear off the long fiber matter to small ones and the pump will discharge it with water. There is no need for filter screen.
  • Perfect design with smaller power of fitted motors and more energy-saving.
  • With new materials for mechanical seal that enable the pump to run safely with more than 8000 hours.
  • With compact structure, movable design, easy to install. It can cut the cost greatly without building pump house.
  • The motor can run smoothly in the complete flow range.
  • The float switch can automatically control the pump to start or turn off in accordance with the water level. There is no need to assign a person to check the pump all the time.
  • Double rail self installation system enables people to install or maintain the pump without entering the cesspool.
  • Equipped with fully automatic. Control cabinet which can protect the pump automatically in case of electric leakage, water leakage and overload etc. The pump set can run more reliable and safely.

Products Applications:

  • Living waster water discharging.
  • Temporary floodwater discharging.
  • Sewage system of municipal works.
  • Water discharging of public facility.
  • Sewage system in factory and mines.
  • Various water-discharging system.
  • Other transportation of corrosive or non-corrosive and diluted medium.
